AV - F7463
METER UNION
3/4"x1" Brass Lugged Meter Union , M/F BS746
Working Conditions:
- Maximum Temperature : 190 C.
- Minimum Temperature : -20 C.
- Maxmum Operating Pressure : 30 Bar.
- Threads : BS EN 746 Female Union x BS EN 21 - BSPT Male.
- Material : BS EN 12165 - CW617.
Table indexes of product
Size
A
B
C
D
E
F
G
H
I
J
K
3/4" x 1"
1" - BS746
11.8 mm
5 mm
29.3 mm
21.1 mm
50.4 mm
R 3/4" BS21
CH.ES.27
2.3 mm
CH.R.23 mm
CH.OTT.42.5 mm
