AV - F612
FEMALE COMPRESSION COUPLING
Brass (CW614N) Adaptors Fittings 1/2" M/F. One end is (G 1/2") internal tapper thread to BS21, the other end is external parallel thread and fitted with a 1/2" brass nut (EN1057) suitable for inserting a single compression olive ring with inner diamater 15mm.
Working Conditions:
- Maximum Temperature : 190 C.
- Minimum Temperature : -20 C.
- Maxmum Operating Pressure : 30 Bar.
- Threads : Female 1/2.
- Material : BS EN 12165 - CW614.
Table indexes of product
Size
A
B
C
D
E
F
G
1/2"
RC 1/2"
34 mm
28.1 mm
9.2 mm
CH. es. 26 mm
CH. es. 24 mm
G 1/2"
