AV - F 7462-II
METER UNION
3/4" Brass Lugged Meter Union, M/F BS746
Working Conditions:
- Maximum Temperature : 190 C.
- Minimum Temperature : -20 C.
- Maxmum Operating Pressure : 30 Bar.
- Threads : BS EN 746 Female Union x BS EN 21 - BSPT Male.
- Material : BS EN 12165 - CW614.
Table indexes of product
Size
A
B
C
D
E
F
G
H
I
J
K
3/4" x 3/4"
3/4"ــ12BS746
10 mm
5 mm
24 mm
21 mm
49.5 mm
R 3/4" BS21
5 mm
2.5 mm
CH.ES.27
CH.ES.27
