AV - 746 MCN
CAP NUT
Brass Cap Nut CW 614N , BS746
Working Conditions:
- Maximum Temperature : 190 C.
- Minimum Temperature : -20 C.
- Maxmum Operating Pressure : 30 Bar.
- Threads : Female BS746 .
Table indexes of product
Size
A
B
C
D
E
F
3/4"
22.1mm
35.5 mm
3 mm
16 mm
4 mm
29.4 mm
1"
27.4 mm
42.5 mm
3.2 mm
18 mm
5 mm
37.2 mm
