AV - 9069
BRASS ADAPTOR COMPRESSION FITTING
Brass (CW614N) Adaptors Fittings 3/8"X1/2" M/F. One end is (Rc 1/2") internal tapper thread to BS21, the other end is external parallel thread and fitted with a 3/8" brass nut suitable for inserting a double compression conical ring with inner diamater from 5.6 to10.2mm.
Working Conditions:
- Maximum Temperature : 190 C.
- Minimum Temperature : -20 C.
- Maxmum Operating Pressure : 30 Bar.
- Threads : Female 1/2.
- Material : BS EN 12165 - CW614.
Table indexes of product
Size
A
B
C
D
E
F
G
H
3/8" x 1/2"
25.5 mm
8.4 mm
16 mm
15 mm
36.5 mm
CH. es. 27
CH. es. 19
Rc 1/2"
