AV - GS79SID
ADAPTOR 1/2" X 10 mm F/M
Brass Adaptors Fittings 1/2". thread to BS21.
Working Conditions:
- Maximum Temperature : 190 C.
- Minimum Temperature : -20 C.
- Maxmum Tperating Pressure : 30 Bar.
- Threads : Female to BS21 .
- Threads : Female 1/2" BS21 - BSPT X Male M10X1 .
- Material : BS EN 12165 - CW614.
Table indexes of product
Size
A
B
C
D
E
F
1/2"
M10 X 1
9 mm
7.7 mm
10.5 mm
G 1/2"
CH. es. 26
