AV - GS81ATS
ADAPTOR 1/2" X 16 MM F / F ( ATLAS SOCKET )
Brass Adaptors Fittings 1/2" . thread to BS21.
Working Conditions:
- Maximum temperature : 190 C.
- Minimum temperature : -20 C.
- Maxmum operating pressure : 30 Bar.
- Threads : Female 1/2" to BS21 BSPT X Female M16 X 1.5 .
- Material : BS EN 12165 - CW614.
Table indexes of product
Size
A
B
C
D
E
F
1/2"
RC 1/2"
31 mm
16 x 1.5 mm
15.5 mm
15.5 mm
CH. ES . 26
