AV1400
Safety Valve For Water-Heater
The safety valve is expressly studied for water heater. The valve is normally calibrated at a pressure of 8 Bars, and so it permits to regulate the boiler, opening automatically at reaching the expected pressure.
Working Conditions:
- Water : Min. 0 C Max. +100 C .
- Nominal pressure : Max. 10 Bar.
- Available in all sizes from : 1/2".
- Thread according to : ISO228 - DIN259 - BS2779 parallel male/female..
Table indexes of product
Items
Body
Nut (1)
Check Valve
Spring (1)
Spring (2)
Washer Holder
Rubber Disk (1)
Rubber Disk (2)
Disk Holder
Spring (3)
Adjusting Nut
Cover Cap
PCs.
1
1
1
1
1
1
1
1
1
1
1
1
Materials
Nickel Plated Brass OT58 UNI 5705
Brass OT58 UNI 5705
Brass OT58 UNI 5705
Stainless Steel
Stainless Steel
NYLON 6
NBR 70 SH A
NBR 70 SH A
NYLON 6
Stainless Steel
NYLON 6
Aluminum Sheet
|
R
|
1/2? | 3/4? | 1? | 1.1/2? | 2? | 2.1/2? | 3? | 4? |
|---|---|---|---|---|---|---|---|---|
|
L (mm)
|
45
|
|
|
|
|
|
|
|
|
H (mm)
|
40
|
|
|
|
|
|
|
|
|
C (mm)
|
|
|
|
|
|
|
|
|
|
D (mm)
|
|
|
|
|
|
|
|
|
|
PN (Bar)
|
10
|
|
|
|
|
|
|
|
|
BOX
|
25
|
|
|
|
|
|
|
|
|
CARTON
|
300
|
|
|
|
|
|
|
|
