AV1000
Non-Return Clapet Valve
Suitable for industrial, pneumatic and hydraulic installations. Ideal for hot/cold water, different oils and compressed air. It can be fitted in horizontal, vertical or oblique position
Working Conditions:
- Air : Min. -20 C Max. +110 C.
- Water : Min. 0 C Max. +90 C .
- Without steam : Min. -20 C Max. + 60 C.
- Nominal pressure : Max. 12 Bar.
- Available in all sizes from : 1/2”- 4”.
- Thread according to : ISO228 - DIN259 - BS2779 / parallel female/female..
Table indexes of product
Items
End adaptor
O-Ring
Body
Plate
Screw
Washer
Seat
Pin
O-Ring
plug
PCs.
1
1
1
1
1
1
1
1
1
1
Materials
Brass OT58 UNI 5705
NBR
Brass OT58 UNI 5705
Brass OT58 UNI 5705
Brass OT58 UNI 5705
Brass OT58 UNI 5705
NBR
Brass OT58 UNI 5705
NBR
Brass OT58 UNI 5705
|
A
|
1/2? | 3/4? | 1? | 1.1/2? | 2? | 2.1/2? | 3? | 4? |
|---|---|---|---|---|---|---|---|---|
|
B (mm)
|
44
|
52
|
62
|
80
|
93
|
|
|
|
|
C (mm)
|
46
|
55
|
63
|
85
|
100
|
|
|
|
|
PN (Bar)
|
10
|
10
|
10
|
8
|
8
|
|
|
|
|
BOX
|
20
|
12
|
10
|
|
|
|
|
|
|
CARTON
|
160
|
96
|
80
|
25
|
40
|
|
|
|
